ABB i-bus KNX AC/S 1.x.1 Series

ABB i-bus
®
KNX
Parameters
262 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Data type
Room setpoint temperature Comfort DPT 9.001
This module has this input socket if the
Yes
option is selected for the
Supply temperature control
parameter, the
Calculated
weather compensated option is selected for the Supply setpoint temperature source parameter and the Based on Scheduler
option is selected for the Economy mode parameter.
Input for the room setpoint temperature in the Comfort operating mode for the heating operating type for the rooms connected
to the heating distribution circuit. The module selects the highest value and uses this value for the Economy mode function to
adjust the heating curve and therefore the supply setpoint temperature to the current needs.
Signal value: -273...670760 °C
Room setpoint temperature Standby
DPT 9.001
This module has this input socket if the Yes option is selected for the Supply temperature control parameter, the Calculated
weather compensated option is selected for the Supply setpoint temperature source parameter, the Based on Scheduler
option is selected for the Economy mode parameter and the Yes option is selected for the Scheduler operating mode Standby
parameter.
Input for the room setpoint temperature in the Standby operating mode for the heating operating type for the rooms connected
to the heating distribution circuit. The module selects the highest value and uses this value for the Economy mode function to
adjust the heating curve and therefore the supply setpoint temperature to the current needs.
Signal value:
-273...670760 °C
Room setpoint temperature Economy DPT 9.001
This module has this input socket if the Yes option is selected for the Supply temperature control parameter, the Calculated
weather compensated option is selected for the Supply setpoint temperature source parameter, the Based on Scheduler
option is selected for the Economy mode parameter and the Yes option is selected for the Scheduler operating mode
Economy parameter.
Input for the room setpoint temperature in the Economy operating mode for the heating operating type for the rooms
connected to the heating distribution circuit. The module selects the highest value and uses this value for the Economy mode
function to adjust the heating curve and therefore the supply setpoint temperature to the current needs.
Signal value: -273...670760 °C
Room setpoint temperature Building Protection
DPT 9.001
This module has this input socket if the Yes option is selected for the Supply temperature control parameter, the Calculated
weather compensated option is selected for the Supply setpoint temperature source parameter, the Based on Scheduler
option is selected for the Economy mode parameter and the Yes option is selected for the Scheduler operating mode Building
Protection parameter.
Input for the room setpoint temperature in the Building Protection operating mode for the heating operating type for the rooms
connected to the heating distribution circuit. The module selects the highest value and uses this value for the Economy mode
function to adjust the heating curve and therefore the supply setpoint temperature to the current needs.
Signal value: -273...670760 °C
