ABB i-bus KNX AC/S 1.x.1 Series

ABB i-bus
®
KNX
Parameters
314 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Data type
Room control values 5.001
The module has this input socket in the following conditions:
• If the Yes option is selected for the Supply temperature control
parameter, the Calculated weather compensated option is
selected for the Supply setpoint temperature source parameter and the Yes option is selected for the Room involvement
parameter.
• If the Yes option is selected for the Switch off if no room demand
parameter.
Input for the "heating" control values (valve positions) for all rooms connected to the heating system. The module selects the
highest value and uses this value for the Room involvement and Switch off if no room demand functions to adjust the heating
curve and therefore the supply setpoint temperature to the current needs.
Signal value:
0…100%
Room setpoint temperature DPT 9.001
This module has this input socket if the Yes option is selected for the Supply temperature control parameter, the Calculated
weather compensated option is selected for the Supply setpoint temperature source parameter and the Based on the current
room setpoint temperatures option is selected for the Economy mode parameter.
Input for the current "heating" room setpoint temperatures for all rooms connected to the heating system. The module selects
the highest value and uses this value for the Economy mode function to adjust the heating curve and therefore the supply
setpoint temperature to the current needs.
Signal value:
-273...670760 °C
Operating mode DPT 20.102
This module has this input socket if the
Yes
option is selected for the
Supply temperature control
parameter, the
Calculated
weather compensated option is selected for the Supply setpoint temperature source parameter and the Based on Scheduler
option is selected for the Economy mode parameter.
Input for the current "heating" operating mode for the rooms connected to the heating system. The module uses this value for
the Economy mode function to adjust the heating curve and therefore the supply setpoint temperature to the current needs.
Signal value:
1 = Comfort
2 = Standby
3 = Economy
4 = Building Protection
