ABB i-bus KNX AC/S 1.x.1 Series

ABB i-bus
®
KNX
Parameters
316 2CDC508198D0211 Rev. A | AC/S 1.x.1
Object name
Data type
Pump fault DPT 1.005
The module has this output socket if the
Yes
option is selected for the
Pump display pump fault status
parameter.
Outputs the fault status provided by the pump.
Signal value:
0 = No alarm
1 = Alarm
Pump repair switch status
DPT 1.011
The module has this output socket if the
Yes
option is selected for the
Display pump repair switch status
parameter.
Outputs the contact position provided by the pump repair switch.
Signal value:
0 = Inactive
1 = Active
Pump override disable/enable
DPT 1.003
The module has this output socket if the Yes option is selected for the Override by WebUI parameter.
Outputs whether the heat generator's pump is overridden.
Signal value:
0 = Disabled
1 = Enabled
Pump override value
DPT 1.001
The module has this output socket if the Yes option is selected for the Override by WebUI parameter.
Outputs the state with which the heat generator's pump is overridden if the pump override is active.
Signal value: 0 = Off
1 = On
Supply setpoint temperature
DPT 9.001
The module has this output socket if the Yes option is selected for the Supply temperature control parameter.
Outputs the current supply setpoint temperature as is sent by the module to the heat generator via the related group object.
The supply setpoint temperature output here is, depending on the setting, either calculated by this module based on the
outside temperature, or specified via an ASM input socket or BACnet and also takes into account any possible override of the
supply setpoint temperature via the web user interface.
Signal value: -273...670760 °C
Supply setpoint temperature External specification
DPT 9.001
This module has this output socket if the Yes option is selected for the Supply temperature control parameter and the BACnet
input object option is selected for the Supply setpoint temperature source parameter.
Outputs the supply setpoint temperature specified via the BACnet object. This status does not take into account any possible
override of the supply setpoint temperature via the web user interface.
Signal value:
-273...670760 °C
