ABB i-bus KNX AC/S 1.x.1 Series

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 323
BACnet input objects
Object name Object type Unit COV send
condition
Heat generator: Supply setpoint temperature External specification
Analog value
°C (62)
-
This module has this BACnet input object if the
Yes
option is selected for the
Supply temperature control
parameter and the
BACnet input object option is selected for the Supply setpoint temperature source parameter.
Input for the specification of the supply setpoint temperature. The value is sent by the module to the heat generator via the
related group object. This supply setpoint temperature specified via BACnet can be overridden manually on the web user
interface.
Signal value:
-273...670760 °C
BACnet output objects
Object name Object type Unit COV send
condition
Heat generator: Return temperature Analog value °C (62) 1.0
Outputs the current return temperature that is received via the related group object.
Signal value:
-273...670760 °C
Heat generator: Supply temperature Analog value °C (62) 1.0
Outputs the current supply temperature that is received via the related group object.
Signal value:
-273...670760 °C
Heat generator: Supply setpoint temperature status Analog value °C (62) 1.0
The module has this BACnet output object if the Yes option is selected for the Supply temperature control parameter.
Outputs the current supply setpoint temperature as is sent by this module to the heat generator via the related group object.
The supply setpoint temperature output here is, depending on the settings, either calculated by this module based on the
outside temperature, or specified via an ASM input socket or BACnet and also takes into account any possible override of the
supply setpoint temperature via the web user interface.
Signal value: -273...670760 °C
