ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 387
Object name
Data type
Supply setpoint temperature DPT 9.001
The module has this output socket if the
Yes
option is selected for the
Supply temperature control
parameter.
Outputs the current supply setpoint temperature as is sent by the module to the chiller via the related group object. The supply
setpoint temperature output here is, depending on the setting, either calculated by this module based on the outside
temperature, or specified via an ASM input socket or BACnet and also takes into account any possible override of the supply
setpoint temperature via the web user interface.
Signal value:
-273...670760 °C
Supply setpoint temperature External specification DPT 9.001
This module has this output socket if the Yes option is selected for the Supply temperature control parameter and the BACnet
input object option is selected for the Supply setpoint temperature source parameter.
Outputs the supply setpoint temperature specified via the BACnet object. This status does not take into account any possible
override of the supply setpoint temperature via the web user interface.
Signal value: -273...670760 °C
Chiller operating status
DPT 1.001
The module has this output socket if the Yes option is selected for the Show operating status parameter.
Outputs the operating status (Off/On) provided by the chiller. Due to the control integrated into the chiller, this status may differ
from the operating status specified by this module.
Signal value: 0 = Off
1 = On
Chiller fault status DPT 1.001
The module has this output socket if the Yes option is selected for the Show fault status parameter.
Outputs the fault status provided by the chiller.
Signal value:
0 = Off
1 = On
