Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 81
Function elements
ASM input socket (SOCKET IN)
Selects the ASM input socket based on the required main data point type. Values receives are forwarded
to the logic.
You can enter a unique name for the element in the Name field in the Properties window. The
corresponding ASM input socket in the Linking view also has this name.
Sending outputs
No.
DPT
Abbr.
Name
Visible
Description
1
Any
A
Output
Always
2 1 bit TE
Telegram
received
Parametrizable
Checkbox selected:
Every telegram received triggers a status send
pulse with the value 1/0.
The next calculation (usually after 200 ms) resets
the value to 0.
Parameters
Name
Value
Visible
Description
Data subtype
According to DPT
Always
Selects the data point type
