Parameters
96 2CDC508198D0211 Rev. A | AC/S 1.x.1
Minimum/Maximum (MIN/MAX)
Finds the largest or smallest of up to 16 values. Inputs can also be linked with fixed values (constant).
Inputs
No.
DPT
Abbr.
Name
Visible
Description
1
1 bit
F
Function
Parametrizable
2
Any
E
1
Input value
Always
3
Any
E
2
Input value
Always
4-16
Any
E
n
Input value
Parametrizable
n = 3...16
Outputs
No.
DPT
Abbr.
Name
Visible
Description
1
1 bit
A
Output
Always
Parameters
Name
Value
Visible
Description
Input count
2…16
Always
Input parameters
Name
Value
Visible
Description
Min Checkbox Always
Enables input F on the
element
Checkbox If the checkbox is cleared
1 = Minimum
0 = Maximum
Function
Input F defines, if MIN or MAX function is activated.
If F = 0, the output sends the largest input value (E1-E16). Function MAX is activated.
If F = 1, the output sends the smallest input value (E1-E16). Function MIN is activated.
The output sends:
• On a value change at the output (new input values will be set).
• When input F receives a value
Other
If only one input is linked, the output value is the same as the input value.
