NoteArticle numberSpare part
Used with protection type Clean
Room.
3HAC077822-001Housing cover, Clean Room
Used with protection type Clean
Room.
3HAC077821-001Lower arm cover, Clean Room
Not used with protection class
IP40.
Replace if damaged.
3HAC070887-001Gasket for process hub
Not used with protection class
IP40.
Replace if damaged.
3HAC067834-001Gasket for tubular cover
Not used with protection class
IP40.
Replace if damaged.
3HAC067833-001Gasket for housing cover
Not used with protection class
IP40.
Replace if damaged.
3HAC067832-001Gasket for lower arm cover
Not used with protection class
IP40.
Replace if damaged.
3HAC032050-001Seal bolt
Not used with protection class
IP40.
Replace if damaged.
3HAC070148-005Radial sealing on lower arm
Used with protection types Clean
Room and Foundry Plus.
Replace if damaged.
3HAC070148-006Radial sealing on housing
Not used with protection class
IP40.
Replace if damaged.
3HAC061327-018O-ring on tubular
Not used with protection type
Clean Room.
Replace if damaged.
3HAC078352-001Plug screw
Used with protection type Clean
Room.
Replace if damaged.
3HAC078351-001Plug screw, Clean Room
Used with protection type Clean
Room.
Replace if damaged.
3HAC075325-001Rubber sealing washer
Used with protection type
Foundry Plus.
3HAC044641-008M2 variseal sealing
Used with protection type
Foundry Plus.
3HAC070148-010Sealing with dust lip
Used with protection type
Foundry Plus.
3HAC075327-001Inner ring cover on tilt unit
Used with protection type
Foundry Plus.
3HAC075326-001Outer ring cover on tilt unit
Used with protection type
Foundry Plus.
3HAC077475-001Gasket for tool mounting
Continues on next page
Product manual - IRB 1300 415
3HAC070390-001 Revision: G
© Copyright 2020-2022 ABB. All rights reserved.
5 Repair
5.5.3 Replacing the tubular and tilt unit
Continued
