NoteEquipment
The content is described in section
Standard toolkit, IRC5 on page 207.
Standard toolkit
Removal
Use the following procedure to remove the SD-card memory.
Action
DANGER
Before commencing any work inside the cabinet, please observe the safety inform-
ation in section DANGER - Make sure that the main power has been switched off!
on page 33.
1
ELECTROSTATIC DISCHARGE (ESD)
The unit is sensitive to ESD. Before handling the unit please observe the safety
information in section WARNING - The unit is sensitive to ESD! on page 34
2
Remove the attachment screw and open the hatch on the right hand side of the
controller.
3
Gently push the SD-card memory with your finger until it clicks, and then pull it
straight out.
4
Refitting
Use the following procedure to refit the SD-card memory.
Action
DANGER
Before commencing any work inside the cabinet, please observe the safety information
in section DANGER - Make sure that the main power has been switched off! on page 33.
1
ELECTROSTATIC DISCHARGE (ESD)
The unit is sensitive to ESD. Before handling the unit please observe the safety inform-
ation in section WARNING - The unit is sensitive to ESD! on page 34
2
CAUTION
Make sure that the SD-card memory is correctly oriented before inserting it. Otherwise
the SD-card memory or the SD-card memory slot may be damaged.
3
Gently push the SD-card memory with your finger until it clicks into place.4
Perform the function tests in section Function tests on page 118 to verify that the safety
features work properly.
5
164 Product manual - IRC5 Compact
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
4 Repair
4.11 Replacement of SD-card memory in computer unit
Continued
