4.5 Replacement of computer unit
Location
The computer unit is located as shown in the illustration below.
A
xx1400001363
Computer unitA
Required equipment
NoteEquipment
See Spare parts on page 209.Computer unit
The contents are defined in section Standard
toolkit.
Standard toolkit
These procedures include references to the
tools required.
Other tools and procedures may be required.
See references to these procedures in the
step-by-step instructions below.
See Circuit diagrams on page 217.Circuit diagram
