ABB IRC5 Compact User Manual

2.6 Connections
2.6.1 Connectors on the IRC5 Compact controller
2.6.1.1 Connectors on the controller
General
The following section describes the connectors on the front panel of the IRC5
Compact controller.
CAUTION
Always inspect the connector for dirt or damage before connecting it to the
controller. Clean or replace any damaged parts.
Connectors
The following details the connection interface on the IRC5 Compact.
E
D
C
B
A
xx1400001372
Description
XS.4 FlexPendant connectionA
Continues on next page
Product manual - IRC5 Compact 55
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
2 Installation and commissioning
2.6.1.1 Connectors on the controller
