4.18 Replacement of Ethernet switch
Location
The following illustration shows the location of the Ethernet switch.
A
B
C
D
xx1500000230
Attachment screwsA
Safety boardB
Ethernet switchC
Remote Service boxD
Required equipment
InformationEquipment
3HAC034884-001Ethernet switch
The content is described in section Standard
toolkit, IRC5 on page 207.
Standard toolkit
Other tools and procedures may be required.
See references to these procedures in the
step-by-step instructions below.
See Circuit diagrams on page 217.Circuit diagram
Continues on next page
184 Product manual - IRC5 Compact
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
4 Repair
4.18 Replacement of Ethernet switch
