Info/illustrationAction
See Replacement of brake resistor
bleeder on page 175.
Refit and connect the brake resistor bleeder.5
Put the fan cover in place and push it to the
right.
6
Fasten the four attachment screws on the
fan cover.
7
Perform the function tests in section Func-
tion tests on page 118 to verify that the safety
features work properly.
8
180 Product manual - IRC5 Compact
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
4 Repair
4.16 Replacement of system fans
Continued
