Power cables, IRB 1200
DescriptionSpare part no.
Control cable power 3 m3HAC040503-007
Control cable power 7 m3HAC040503-001
Control cable power 15 m3HAC040503-002
Control cable power 22 m3HAC040503-003
Control cable power 30 m3HAC040503-004
Ethernet cables, IRB 1200
Option no.DescriptionArt. no.
859-9Ethernet cable 3 m3HAC055518-001
859-1Ethernet cable 7 m3HAC055518-002
859-2Ethernet cable 15 m3HAC055518-003
859-3Ethernet cable 22 m3HAC055518-004
859-4Ethernet cable 30 m3HAC055518-005
Signal cables, IRB 1410, 1600
DescriptionArt. no.
Control cable signal 7 m3HAC2493-1
Control cable signal 15 m3HAC2530-1
Control cable signal 22 m3HAC2540-1
Control cable signal 30 m3HAC2566-1
Power cables, IRB 1410, 1600
DescriptionArt. no.
Control cable power 7 m3HAC2492-1
Control cable power 15 m3HAC2529-1
Control cable power 22 m3HAC2539-1
Control cable power 30 m3HAC2564-1
Control cable power 7 m3HAC9038-1
Control cable power 15 m3HAC9038-2
Control cable power 22 m3HAC9038-3
Control cable power 30 m3HAC9038-4
CP/CS cables IRB 1600
Option no.DescriptionArt. no.
94-1, 16-1 and 17-5Cable CP/CS 7 m3HAC061420-001
94-2, 16-1 and 17-5Cable CP/CS 15 m3HAC061420-002
94-3, 16-1 and 17-5Cable CP/CS 22 m3HAC061420-003
Continues on next page
Product manual - IRC5 Compact 215
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
7 Spare parts
7.2 Manipulator cables
Continued
