LAN 2 can only be used as private network to the IRC5 controller.
Isolated LAN 3 or LAN 3 as part of the private network (only for RobotWare 6.01 and later)
The default configuration is that LAN 3 is configured as an isolated network. This
allows LAN 3 to be connected to an external network, including other robot
controllers. The isolated LAN 3 network has the same address limitations as the
WAN network.
WAN
LAN 2
LAN 3
Private
Robot Controller
LAN 1
Service
Public
Isolated
LAN 3
xx1500000393
An alternative configuration is that LAN 3 is part of the private network. The ports
Service, LAN 1, LAN 2, and LAN 3 then belong to the same network and act just
as different ports on the same switch. This is configured by changing the system
parameter Interface, in topic Communication and type Static VLAN, from "LAN 3"
to "LAN". See Technical reference manual - System parameters.
WAN
LAN 2
LAN 3
Private
LAN 1
Service
Public
Robot Controller
xx1500000394
Note
For more information and examples of connecting to different networks, see
Application manual - EtherNet/IP Scanner/Adapter or Application
manual - PROFINET Controller/Device.
USB ports
The USB ports are intended for connecting USB memory devices.
Note
It is recommended to use the USB ports USB
1
and USB
2
on the X10 connector
for connecting USB memory devices.
The USB ports on the X11 connector are intended for internal use.
60 Product manual - IRC5 Compact
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
2 Installation and commissioning
2.6.1.3 Connectors on the computer unit
Continued
