ArgumentsDescriptionInstruction
\Stop: the robot will stop as fast
as possible. This stop is per-
formed by ramping down motion
in each motor separate from each
other, and as fast as possible.
Since it will be without any coordin-
ation, the robot may slide off path
fairly much.
Search instructions can be pro-
grammed with arguments to stop
the robot movement close to the
point where a search hit was no-
ticed. The program execution will
continue with the next instruction.
SearchX
\PStop: the robot will stop like
after a normal program stop.
\SStop: the robot will stop on path
but quicker than a normal program
stop. This is similar to a system
input SoftStop.
\Sup: the robot will continue to the
ToPoint. If more than one search
hit is found, an error will be repor-
ted.
RAPID instructions valid for IRC5 are described in Technical reference
manual - RAPID Instructions, Functions and Data types.
Other unexpected stops
DescriptionType of stop
In the control system there is a surveillance and monitoring
function that can detect abnormal situations. In such cases a
stop will be initiated. The robot controller must be restarted.
SysFail
In the control system there is a monitoring function that can
detect power failure. In such cases a stop will be initiated.
Power fail
In the control system there is a monitoring function that can
detect collisions. In such cases a stop will be initiated.
WARNING
Special care must be taken when restarting a machine that is
stopped due to a collision. The robot might make a limited
movement when restarted.
Stop at collision
WARNING
The revolution counters might need to be updated after a colli-
sion to ensure path accuracy.
Product manual - IRC5 Compact 87
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
2 Installation and commissioning
2.6.9 Programmable stop functions
Continued
