ProcessMaster FEP610, HygienicMaster FEH610 | OI/FEP610/FEH610-EN Rev. B 55
Menu / parameter Description
Device Setup / ...Transmitter / ...Units
Unit Massflow Qm Selection of unit for mass flow.
Refer to "Available units" on page 49.
The selection applies to the display of the current mass flow, and for the parameters related to mass flow such as
QmMax and Qm
Max
DN.
Unit Mass Tot.
Selection of unit for the mass totalizer.
Refer to "Table 3: Units for the mass totalizer" on page 49.
Unit Volumeflow Qv Selection of unit for volume flow.
Refer to "Table 1: Units for the volume flow" on page 49.
The selection applies to the display of the current volume flow and for the parameters related to volume flow such
as QvMax and Qv
Max
DN.
Unit Vol. Totalizer
Selection of unit for the volume totalizers.
Refer to "Table 4: Units for the volume totalizer" on page 49.
Cust Qm Tot Unit F. Enter the factor for a user-defined massflow unit. The factor relates to the flow per liter.
Cust Qm Tot Unit N. Enter the name for the user-defined massflow unit.
Cust Qv Tot Unit F.
Enter the factor for a user-defined volumeflow unit.
The factor relates to the flow per liter.
Cust Qv Unit N.
Enter the name for the user-defined volumeflow unit.
Device Setup / ...Transmitter / ...Cut Off
Low Flow Cut Off Sets the switching threshold (0 ... 10 %) for the low flow cut-off.
If the flow rate is below the switching threshold, there is no flow measurement. The setting of 0 % deactivates the
low flow cut-off.
Default setting: 1.0 %
Low Flow Hysteresis Sets the hysteresis (0 ... 50 %) for the low flow cut-off as it is defined in the parameter "Low Flow Cut Off".
Default setting: 20 %
Device Setup / ...Transmitter / ...Feature Settings
Verifying Capab. Indicates whether the Verification function is enabled.
Verifying Capab.Code Sets the device-specific code for activating the Verification function. To use this function subsequently, contact the
ABB service team or sales organization.
After entering the code, restart the device (e.g. using the parameter "Device Reset" or by briefly switching off the
power supply).
Device Setup / ...System Zero
Manual Adjust Sets the value for zero point adjustment in % of Q
max
DN.
Manual Adjust: -50 ... +50 mm/s
Auto Adjust
Starts the automatic zero point adjustment using . Automatic zero point adjustment takes approx. 60 seconds.
NOTE
Prior to starting the zero point adjustment, make sure that:
— There is no flow through the sensor (close valves, shut-off devices etc.).
— The sensor must be filled completely with measuring medium for measurement.
