7 - Operation
LED status Operating state
green:
yellow:
red:
Ventilation anomaly
Indicates ananomaly in the operation of the internal ventilation system that could limit output
power at high ambient temperatures.
Overvoltage surge arresters triggered (where tted)
Indicates that any class II overvoltage surge arresters installed on the AC or DC side have
been triggered
Internal statistics memory anomaly
Indicates an operating anomaly in the internal memory on which the inverter statistics are
stored
Buffer battery discharged
The buffer battery is low and the inverter does not maintain the time setting
green:
yellow:
red:
Initial conguration failure
The inverter is in locked state due to a failure in the initial conguration of the equipment,
such as the standard network setting for the country of installation
Self-test not carried out (for Italian grid standards only)
Self-test operation failure
Incompatibility of the device rmware versions
The rmware versions of the various devices comprising the equipment are incompatible
and are being updated (this is an automatic operation)
Temperature sensor anomaly detected
green:
yellow:
red:
Updating the rmware from an SD card
The equipment rmware is being updated from an SD card
* lighting of
the LEDs in
sequence
green:
yellow:
red:
Updating the rmware from an SD card has failed
The equipment rmware update from an SD card has failed
green:
yellow:
red:
Updating the rmware from an SD card completed
The equipment rmware has been successfully updated from an SD card
*blink 3 times
green:
yellow:
red:
Remote OFF activated
The Remote Off command has been activated.
The unit will not connect to the network until the remote ON command has been activated
