ABB PVS-100 User Manual

- 19 -
000825BG
2 - Characteristics
Characteristics and technical data
Table: Technical Data PVS-100-TL PVS-120-TL
Input
Absolute maximum input voltage (Vmax,abs) 1000 V
Input start-up voltage (Vstart) 420 V (400 - 500 V)
Input operating interval (Vdcmin...Vdcmax) 360 - 1000V
Rated input voltage (Vdcr) 620 Vdc 720 Vdc
Input nominal power(Pdcr) 102000 W 123000 W
Number of independent MPPT 6
MPPT DC voltage range (VMPPTmin ... VMPPTmax) to Pacr 480 - 850 Vdc 570 - 850 Vdc
Maximum DC input power for each MPPT (Pmppt,max)
17500 W
[480V≤VMPPT≤850V]
20500 W
[570V≤VMPPT≤850V]
Maximum DC input current for each MPPT (Idcmax) 36 A
Maximum short circuit current for each MPPT (Iscmax) 50 A
Maximum return current (AC side vs DC side) Negligible in normal operating conditions
(1)
Number of DC input pairs for each MPPT 4
Type of input DC connectors PV quick t connector
(2)
Type of photovoltaic panels that can be connected at
input according to IEC 61730
Class A
Input protection
Reverse polarity protection Yes, from current limited source
Input over voltage protection for each MPPT -
modular surge arrester
Type II with monitoring only for SX and SX2 versions;
Type I+II with monitoring only for SY and SY2 versions
Photovoltaic array isolation control as per IEC62109
DC switch rating for each MPPT 50 A / 1000 V
(3)
Fuse rating (versions with fuses) 15 A (gPV/1000 Vdc)
(4)
String current monitoring
SX2, SY2: Individual string current monitoring (24ch);
SX, SY: Input current monitoring per MPPT (6ch)
Output
AC Connection to the grid Three phase 3W+PE or 4W+PE
Nominal AC Output Power (Pacr @cosφ=1) 100 000 W 120 000 W
Maximum AC Output Power (Pacmax @cosφ=1) 100 000 W 120 000 W
Maximum apparent Output power (Smax) 100 000 VA 120 000 VA
Rated AC Output Voltage (Vacr) 400 V 480 V
Output voltage range (Vacmin...Vacmin) 320...480 V
(5)
384...576 V
(5)
Maximum output current (Iacmax) 145 A
Contribution to short-circuit current 155 A
Rated Output Frequency (fr) 50 Hz / 60 Hz
Output Frequency Range (fmin...fmax) 45...55 Hz / 55…65 Hz
(6)
Nominal power factor and setting interval > 0.995, 0...1 inductive/capacitive with maximum Smax
Total harmonic distortion of current <3%
Maximum AC cable section allowed 185 mm
2
copper/aluminum
AC Connections Type
Busbar for lug connections with M10 bolts (provided);
Single core cable gland plate with 5 individual AC cable glands: 4
x M40: Ø 19...28mm, 1 x M25: Ø 10...17mm
Output protection
Anti-islanding Protection
Active frequency drift combined with RoCoF techniques
as per IEC 62116
Maximum external AC overcurrent protection 225 A
Output overvoltage protection -
Modular surge arresters
Type 2 with monitoring
Operating performance
Maximum Efciency (ηmax) 98.4% 98.9%
Weighted Efciency (EURO) 98.2% 98.6%

ABB PVS-100 Specifications

General

Rated AC power output	100 kW
AC Voltage	400 V
Topology	Transformerless
Cooling Method	Forced Air
Operating temperature range	-25°C to +60°C (derating above 45°C)
Cooling	Forced air
Frequency	50/60 Hz
