ABB PVS-100 User Manual

- 21 -
000825BG
2 - Characteristics
Tightening torques
To maintain the IP66 protection of the system and for optimal installation,
the following tightening torques must be used:
Tightening torques
Single core AC cable gland
11
M40
5 Nm
Single core PE cable gland
11
M25
5 Nm
Multi core AC cable gland
11
M63
18 Nm
Service cable gland
12
M25
5 Nm
AC connection busbar
21
bolts
25 Nm
AC interface power connector (male)
24
screws
3 Nm
DC interface connector (male)
17
screws
3 Nm
Protective earth point (int.)
25
nut
21 Nm
Protective earth point (ext.)
10
nut
12 Nm
Junction screws
18
12 Nm
Side bracket screws 5 Nm
Interface signal connector counterparts
32 34 35
0.25 Nm
Cable gland clamping range
Cable gland clamping range
Single core AC cable gland
11
M40
19...28mm
Single core PE cable gland
11
M25
10...17mm
Multi core AC cable gland
11
M63 (type1)
34...45mm
Multi core AC cable gland
11
M63 (type2)
37...53mm
Service cable gland
12
M25
10...17mm
