ABB PVS-100 User Manual

- 20 -
000825BG
2 - Characteristics
Table: Technical Data PVS-100-TL PVS-120-TL
Communication
Embedded communication interfaces
1x RS485, 2x Ethernet (RJ45),
WLAN (IEEE802.11 b/g/n @ 2,4 GHz)
User Interface 4 LEDs, Web User Interface, Mobile APP
Communication protocol Modbus RTU/TCP (Sunspec compliant)
Commissioning tool Web User Interface, Mobile APP
Remote monitoring services Aurora Vision® monitoring portal
Advanced features Embedded logging, direct telemetry data transferring to ABB cloud
Environmental
Ambient temperature range -25...+60°C /-13...140°F with derating above 40°C / 104 °F
Storage temperature -40°C...+85°C / -40°F...185°F
Relative Humidity 4…100 % with condensation
Typical noise emission pressure 68 dB(A) @ 1 m
Maximum operating altitude 2000 m / 6560 ft
Environmental pollution degree
classication for external environments
3
Environmental class Outdoor
Climatic category according to IEC 60721-3-4 4K4H
Physical
Environmental Protection Rating IP 66 (IP54 for the cooling section)
Cooling System Forced air
Dimensions (H x W x D)
867x1086x419 mm / 34.2”x42.7”x16.5” for -SX, -SY model
867x1086x458 mm / 34.2”x42.7”x18.0” for -SX2, SY2 model
Weight
70kg / 154 lbs for power module ;
~55kg / 121 lbs for Wiring box
Overall max ~125 kg / 276 lbs
Assembly System Mounting bracket vertical & horizontal support
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Insulation Level Transformerless
Marking CE
Safety, EMC and Radio Spectrum Standards
IEC/EN 62109-1, IEC/EN 62109-2, EN 61000-6-2, EN
61000-6-4, EN 61000-3-11, EN 61000-3-12, EN 301 489-1,
EN 301 489-17, EN 300 328, EN 62311
Grid standard (check the availability with your sales
channel)
CEI 0-16, CEI 0-21
(7)
, IEC 61727, IEC 62116, UTE C 15 712-
1, JORDAN IRR-DCC-MV, IEC 60068, IEC 61683
Accessories
Assembly accessories
PVS Installation Kit
AC multicore cable gland plate (Supports M63 Ø 34…45mm
+ M25 Ø 10...17mm)
AC multicore cable gland plate (Supports M63 Ø 37…53mm
+ M25 Ø 10...17mm)
1. In the event of a fault, limited by the external protection envisaged on the AC circuit
2. Please refer to the document “String inverters – Product manual appendix” available at www.abb.com/solarinverters for informa-
tion on the quick-t connector brand and model used in the inverter.
3. 75A 5 cycles according to standard IEC60947.3 Table D.5
4. Maximum fuse size supported 20 A. Additionally two specic string inputs per MPPT supports 30 A fuse sizes for connecting two
strings per input.
5. The output voltage range may vary according to the grid standard of the country of installation
6. The output frequency range may vary according to the grid standard of the country of installation
7. Only available for PVS-100-TL model.
Note. Features not specically mentioned in this data sheet are not included in the product
