- 151 -
000846BG
8 - Maintenance
- Error code
- Error message
- LED status
Name of Alarm and Cause Solution
- W013
- Clock Fail
-
Flashing yellow
LED
Clock Fail:
The alarm occurs when there is a difference of
more than 1 minute in the time shown on the Web
User Interface compared to the internal time of the
microprocessors and indicates a malfunction of the
clock circuit.
• Error inside the inverter and cannot be checked externally.
- If the alarm repeats persistently, contact customer
assistance.
- W015
- Island Detect.
-
Yellow LED
Disconnection due to Anti-Islanding:
The inverter has been improperly connected to an
island grid.
• Check that the grid to which the inverter is connected is not
an island grid.
- If the grid to which the inverter is connected is an island
grid, switch the inverter off and then on again: if the problem
persists, contact customer assistance.
- W018 *
- DC SPD tripped
-
Flashing yellow
LED
* (only for models with
monitored SPD)
Intervention of overvoltage surge arresters on DC
side:
Overvoltage surge arresters situated on the DC side
are damaged.
• Observe the inspection window on each surge arrester
(DC side). If it is red, the surge arrester is damaged and the
cartridge must be replaced.
- If the alarm status persists, even if all the surge arresters
have a green inspection window, contact customer assistance.
- W019 *
- AC SPD tripped
-
Flashing yellow
LED
* (only for models with
monitored SPD)
Intervention of overvoltage surge arresters on AC
side:
Overvoltage surge arresters situated on the AC side
are damaged.
• Observe the inspection window on each surge arrester
(AC side). If it is red, the surge arrester is damaged and the
cartridge must be replaced.
- If the alarm status persists, even if all the surge arresters
have a green inspection window, contact customer assistance.
W021
- P-reductionStart
- No LED
Activation of reduction in power:
Indicates that one of the power limitations has been
triggered.
• Check which power limitation code is active and, on the
basis of that, carry out the necessary checks that might relate
to various factors including:
- settings by the user
- high grid frequency
- high grid voltage
- anti-islanding
- low grid voltage
- high internal temperature
- high input voltage
- W022
- Q-modeChange
- No LED
Variation in means of managing reactive power:
Variation in the means of managing reactive power;
this change can be made through the Web User
Interface.
The variation in the means of managing reactive power is
done directly by the customer/installer and is not an error. The
information is only saved on the historic record of the events
memorised by the inverter.
- W023 *
- Date/time mod.
- No LED
Variation in the inverter's date and time:
Variation of the inverter's date and time; this change
can be made through the Web User Interface.
The variation in the inverter's date and time is done directly
by the customer/installer and is not an error. The information is
only saved on the historic record of the events memorised by
the inverter.
- W024
- Energy data rst
- No LED
Zeroing of the statistical energy data memorised
in the EEPROM:
Reset of the energy data saved in the inverter; this
operation can be handled through the Web User
Interface.
The zeroing of the partial energy values memorised by the
inverter is done directly by the customer/installer and is not an
error. The information is only saved on the historic record of
the events memorised by the inverter
The warning may also occur when the Memory Card on
which the production statistics are saved is replaced
W025
- P-reductionEnd
- No LED
Deactivation of reduction in power:
Indicates that the inverter has come out of one of the
power limitation states.
This type of warning does not need any check
- W046
- Grid conn. fault
-
Yellow LED
Connection to the grid unsuccessful
The alarm is logged when a Missing grid or Input UV
error occurs or due to the manual disconnection of the
inverter during the grid connection sequence.
• Once the error occurs, the inverter tries to return to normal
operation.
If the problem persists after a number of attempts to connect
the inverter, switch the inverter off and then on again.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- W047
- Update Incomplete
-
Yellow LED
FW update method unsuccessful
The alarm occurs when a rmware update has not
been completed.
• Complete any pending rmware updates.
- If the problem persists once the rmware updates have been
completed, switch the inverter off and on again.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- W048
- Periodic GridOff
-
Yellow LED
Automatic disconnection from the grid due to time
limit:
If the inverter exceeds the set grid connection time
limit set by the grid standard, it will automatically have
to carry out a disconnection and reconnection to the
grid to carry out the Riso test.
The presence of this alarm is not an error as the automatic
disconnection is prescribed by safety regulations.
- If the inverter disconnects in a shorter time than expected,
contact customer assistance.
