18 Hardware description
Layout drawing (dry-type variant)
Compartments
Sec. Description
A Inverter section
B Transformer enclosure
C Low-voltage enclosure
D Medium-voltage enclosure
1
1
2
2
3
4
5
6
7
8
9
10
11
12
C
B
A
D
