Option codes
Code Name Description
Fieldbus
K458 Modbus RTU
adapter
Inverter is equipped with an adapter for Modbus RS485 connections. The
used adapter is called FSCA-01. For more details, see FSCA-01 manual.
K473 Ethernet
adapter
(Ethernet/IP,
Modbus/TCP,
PROFINET)
Inverter is equipped with an adapter for Ethernet/IP, Modbus/TCP, PROFINET
connectivity. The used adapter is called FENA-11. For more details, see
FENA-01/-11/-21 manual.
K475 Ethernet
adapter
(Ethernet/IP,
Modbus/TCP,
PROFINET,
2-port)
Inverter is equipped with an adapter for Ethernet/IP, Modbus/TCP, PROFINET
connectivity. The used adapter is called FENA-21. The difference to FENA-11
is that FENA-21 has dual Ethernet ports for daisy chaining the inverters. For
more details, see FENA-01/-11/-21 manual.
K480 Ethernet
switch
Inverter is equipped with an Ethernet switch from Phoenix contact. The switch
has 2 fiber optics and 6 RJ-45 ports for inverter and auxiliary device
connectivity. For more details, see PVS980 Commissioning and maintenance
manual and Phoenix contact documentation.
Remote monitoring
K486 ABB remote
monitoring
Inverter is equipped with an adapter for remote monitoring. The used adapter
is called NETA-21. The adapter is mainly intended for small scale power
plants. For more details, see NETA-21 manual.
AC section options
F296 AC breaker,
motorized,
remote
control (not
with +F253)
Inverter is equipped with a controllable, configurable AC breakers (one per
power section). Even with the breakers, inverter is always equipped also with
AC fuses. This option is not possible with F253, AC disconnector.
F263 AC surge
arrester, high
energy, Type
1, complies
also with
Type 2
Standard Type 2 surge arresters replaced with high energy Type 1 surge
arresters that fulfill also Type 2 requirements. Provides better protection for
surges.
G317 AC output
with busbar
(close
coupling)
interface
Inverter side has output for direct busbar connection. This provides only the
connection point, additional covers and insulations need to be handled by site
designer. Dimensioning is suitable only for direct busbar connection, not for
cables.
F253 AC
disconnector
(not with
+F296)
Inverter is equipped with a manual AC disconnectors (one per power section).
The disconnectors are meant for isolation purposes and the AC fuses are
used for inverter protection. This option is not possible with F296, AC breaker.
DC section options
F282 Grounding,
positive DC
(Functional
Grounding)
Positive DC pole is functionally grounded. DC fuses are installed only on the
non-grounded terminals.
F314 Floating DC
(fuses on
both poles)
Neither DC potentials are grounded, meaning that the input is floating. DC
fuses are installed to both DC potentials.
