Technical data 61
10
Technical data
For component-specific technical data, refer to the applicable documentation for the
components of the megawatt station.
For information on the inverters, refer to the PVS980 hardware manual
(3AXD50000026013 [EN]).
Type designation
PVS980-MWS-
3636kVA-I 3818kVA-J 4000kVA-K 4182kVA-L
Maximum rating 4000 kVA 4200 kVA 4400 kVA 4600 kVA
Input data (DC)
Maximum input power (P
PV, max
) 2x 2909 kWp 2x 3056 kWp 2x 3200 kWp 2x 3346 kWp
DC voltage range, mpp (U
DC,
mpp
) @ 35 °C (95 °F)
850...1500 V 893...1500 V 935...1500 V 978...1500 V
DC voltage range, mpp (@ S
nom
)
@ 50 °C (122 °F)
850...1100 V 893...1100 V 935...1100 V 978...1100 V
Maximum operational DC voltage
(U
DC, max
)
1500 V
Protected DC inputs (parallel) 2x 8 (up to 24 as option)
MPPT trackers 2
Output data (AC)
Inverter type (2x ABB central
inverter)
PVS980-58-
1818kVA-I
PVS980-58-
1909kVA-J
PVS980-58-
2000kVA-K
PVS980-58-
2091kVA-L
Nominal AC output power (S
AC,
N
) @ 50 °C (122 °F)
3636 kVA 3810 kVA 4000 kVA 4182 kVA
Maximum AC output power (S
AC,
MAX
) @ 35 °C (95 °F)
4000 kVA 4200 kVA 4400 kVA 4600 kVA
Medium voltage range (U
AC, N
) 12 kV to 36 kV
