62 Technical data
Output frequency 50/60 Hz
Harmonic distortion, current < 3%
Power factor compensation
(cos φ)
Yes
Transformer type ABB Vacuum cast coil dry type (AF) or ABB Oil immersed type (ONAN)
Medium voltage switchgear type ABB SafeRing, SF6-insulated, DeV, CV or CCV
Enclosure Painted steel outdoor enclosure, IP54, C4 corrosion protection
Efficiency
Maximum (inverter only) 98.8%
Euro-eta (inverter only) 98.6%
Power consumption
In normal operation ≤ 5500 W / ≤ 7500 W
In stand-by ≤ 800 W
Aux. voltage for customer use 3-phase 400 V/50 Hz, up to 40 kVA
Dimensions and weight
Width / Height / Depth 3180 / 2366 / 1519 mm
(125.20 / 93.15 / 59.80 in.)
Weight approx. < 30 t
Environmental limits
Degree of protection Inverter IP56/IP66, UL Type 3R.
IP44/54 RMU and dry type transformer housing
Ambient temperature range
(nominal ratings)
-20 °C…+50 °C (-4 °F…+122 °F)
Maximum altitude (above sea
level)
1000 m
Relative humidity, non-
condensing
5%...95%
Type designation
PVS980-MWS-
3636kVA-I 3818kVA-J 4000kVA-K 4182kVA-L
