41Control Board settings and reboarding
The following parameters can be adjusted in the Control Board, regardless of the selected operating mode.
Parameter Description
Only for Extender as standalone:
Start / stop charging
Start or stop the charging process for the charge point, provided a vehicle is connected.
Lock / unlock charging cable
Permanently lock the connected charging cable in the charging socket of the wallbox and
unlock it again at a later date.
Please note: In a charging group, you can perform this function globally for all wallboxes.
Overview/Diagnostics
View various information about the charge point (such as charging current and status as
well as operational readiness, etc.) as well as faults and errors in operation.
Settings > Infrastructure settings
View and change the current settings for maximum fuse protection of the charging
station, phase imbalance detection and load shedding.
Settings > Network Allows you to view and change the current network settings.
Only for Extender as standalone:
Settings > Access control
Remove RFID media that have already been configured and add new media for
authorisation.
Settings > Password management Allows you to view and change the current password for the charging station.
Settings > Update Allows you to install new software on the wallbox as soon as it is available.
Settings > Reset to factory settings
Reset all parameters and settings of the wallbox(es) to the factory settings: this automati-
cally breaks up configured charging groups.
Settings > Language
Switch the user language of the app between DE, EN, FR, IT and NL after the initial
setup.
Settings > Help & FAQ Redirects to the ABL support website.
Settings > Download configuration
report
Allows you to generate a report of all current settings (charging currents, RFID UIDs,
phase imbalance, etc.) and then send it by email.
Settings > Request diagnostic file Request a diagnostic report and save it on your mobile device.
When you leave the Control Board, the connection to the Controller/Extender wallbox is terminated. When you reconnect to the
Controller later, you will be redirected automatically to the mode selection screen (Start new configuration or Existing configuration).
