59Technical specifications
Product number 100000151
Dimensions (H×W×D) 516×306.5×145mm (W: 290mm without protrusions)
Weight per wallbox Approx. 7.2kg
eM4Single Extender series
Product number 100000157
Type 4WS-22ENS2
Rated voltage 230/400V
Grid frequency 50Hz
Current 32A
Maximum output 1 × 22kW (3-phase)
Charging connection
Lockable Type2 charging socket in acc. with IEC62196-2
Phase system 3-phase (1-phase connection possible)
Terminal blocks
Direct connection to the terminal block, supply cables up
to a maximum of 10mm² or cable diameters ≤ 25mm
Upstream fuse 32A (required onsite), C characteristic recommended
Rated insulation voltage (Ui) 4kV
Rated impulse voltage (Uimp) 4kV
Rated impulse withstand current (Ipk) 6kA
Rated short-time withstand current (Icw) 5kA
Conditional rated short-circuit current (Icc) 6kA (tripping characteristic C)
Rated diversity factor (RDF) 1.0
Residual Current Devices RCCB, TypeA, 30mA
DC fault current detection DC-RCM, I
Δn d.c.
≥ 6mA
Overcurrent protection Integrated into firmware, disconnection above 120% after 10seconds
Energy meter MID compliant
Load switching Installation contactor, 4-pole, 40A
Weld detection No charging possible with welded contactors
Temperature monitoring Internal, charging current reduction or shut down
Optional ventilation function of the vehicle Not supported
RFID standard ISO14443, UID only (4-byte/7-byte), ISO 15693 and ISO 18092
Access control RFID, QR code or smartphone app
Backend communication Via Controller wallbox
Supported protocols for external systems OCPP 1.5 + 1.6, OCPP Smart Charging, Modbus TCP
Communication Controller LAN, WLAN
Load shedding / external release contact
Terminal for connecting a control cable,
e.g. in accordance with VDE-AR-N 4100
Use (in accordance withIEC 61439-7) AEVCS
Earthing system TN-S
Operating temperature -25°C to 40°C
Storage temperature -25°C to 70°C
Relative humidity 5 to 95%, no condensation
Class of protection I
Degree of protection (housing) IP55
Overvoltage category III
Degree of pollution 3
Impact strength IK10
Power dissipation 5W
