Accu-Chek ACTIVE User Manual

67
Using the meter as a diary
5–20 cm
4 Place the meter approx. 5-20 cm away from the
infrared port of the receiving end. Position the
two infrared ports so that they are facing to-
wards one another.
5 If necessary, start the test result download at the
receiving end (software product or hardware).
The meter automatically downloads all of the results
from its memory. While the data is downloaded,
does not ash.

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
