Using the meter as a diary
1 Read the operating instructions supplied with the
software and hardware you are using. There you
will nd all the information needed for down-
loading data.
2 Prepare the receiving end (software product or
hardware) for downloading the test results.
3 With the meter turned off, press and hold the M
button (for more than 3 seconds) until
ashes
in the display.
Press for more than 3
seconds

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
