Acer P5271 - Page 105

P5271/P5290/P5390W/P5271i
Condential
III
Item P/N Description Parts Supply
70.8BV45GR01
ASSY TOP&LAMP COVER MODULE
P5271(SERVICE)
V
1 51.8BV10H002 TOP COVER P5271i
2 61.8BV17H001 LAMP COVER SPRING P5271
3 70.8BV19G001 KEYPAD MODULE P+R P5271
4 85.YA121G030 SCREW FLAT HEAD TAP M1.7*3 Ni
5 75.8BV05G002 ASSY LAMP COVER MODULE P5271i
6 51.8BV21H001 ACER LOGO TOP PLASTIC P5271
6
5
1
3
4
2
ASSY TOP COVER MODULE
