P5271/P5290/P5390W/P5271i
Condential
II
Item P/N Description Parts Supply
70.8BV44GR01 ASSY FRONT COVER MODULE P5271(SERVICE) V
1 75.8BV08G002 ASSY FRONT COVER P5271i
2 51.8BV12H001 FRONT IR LENS P5271
3 80.8BV05G001 PCBA IR BD FOR P5271
4 42.85E04G001
W.A. 3P #28 L230mm WITH L165mm GASKET IR
RECEIVER DV11
5 61.8BV11H001 ACER LOGO FRONT P5271
6 51.8BV11G002 FRONT IR MYLAR P5271i
7 51.8BV24H001 FRONT LIGHT CUT P5271
6
7
3
4
5
2
1
ASSY FRONT COVER MODULE
