P5271/P5290/P5390W/P5271i
Condential
VII
Item P/N Description Parts Supply
1 75.8BV01GP01
ASSY MATRITEK 230W LVPS FOR P5271.
STAND-BY<1W (P5271)
V
1 75.8BV02GP01
ASSY MATRITEK 280W LVPS .STAND-BY<1W
(P5290/P5390W)
V
2 42.00451G001
W.A. 16P 240mm LVPS TO MAIN BD UL1007
EP752
V
3 42.83M06G001
CABLE W.A. 2P #20 180mm LAMP DRIVER TO
LVPS 2400MP
V
4 85.1F123G060 SCREW PAN MECH W/SF M3*6 Ni GREEN
ASSY LVPS MODULE
3
2
4
1
4
