Acer P5271 - Page 112

P5271/P5290/P5390W/P5271i
Condential
X
Item P/N Description Parts Supply
1 49.83C04G001 SUNON 9225 AXIAL FAN/KDE1209PTBX V
2 52.8BV06H001 FAN 9225 RUBBER BOTTOM P5271
3 52.L1309G002 FAN 9225 RUBBER TOP FOR PD726
4 61.89547G001 92*25 FAN SCREW M2.6 4100MP
5 61.8BV05H001 FAN 9225 BRACKET P5271
6 41.8AV01G001 EMI GASKET W6*H3*L50
ASSY FAN MODULE
5
2
1
4
3
6
