― 19 ―
Please fasten the bolting torque of an
Accelerometer and Contact pin by 1 - 1.5
N-m.
An Accelerometer is a product made from
an aluminum alloy.
Please apply a thin of silicon grease to the
screw parts and you can mount smoothly.
Preparation
Forcing by the contact pin
Measure in the place of an unfixable narrow place or a thin pipe where does not have sufficient
contact surface product using a contact pin.
Although it is the easiest method, 500 or more Vibration measurement cannot be performed
because Contact Resonant Frequency falls very much,
Accelerometer
TYPE 7812B
Contact pin
Fixation a double-sided tape
When Vibration frequency is low, and amplitude is small, it can fix with double-sided adhesive
tape.
