ACO 3116 - Menu and Cursor Operations

― 7 ―
Names and functions of various parts
Menu
It pushes, when setting up measurement conditions. Calendar adjustment etc. There are
three Menu screens to 1/3-3/3. If it pushes 4 times, it will return to a standard screen.
＊＊＊＊
is a setting value at the time of factory shipments.
Menu 1/3 Meas ：
Manu
；Measurement
Mem Clr ；Memory data clearance
Mem Call ；Memory data call
I/O ：
OFF
；The data output OFF
to external apparatus
Printer ；Output to a printer
PC ；Output to a PC
Date ：
2000／01／01
；year／month／day
Time ：
00：00：00
；hour：minute：second
Menu 2/3 Range ：200，
20
（In the case of displacement 2000，200）
Mode ：
m/s
2
（Acceleration），mm/s（Velocity），μm（Displacement）
Filter ：
OFF
（Acceleration），1kHz（Velocity），300Hz（Displacement）
※Mode and linkage（An single setup is impossible）
Conv ：RMS，EQPP（EQp-p Only displacement）
EQPK
（EQPeak），PEAK
Disp Time ：
1s
；Indication period(Data display) display it every 1second
2s ；Indication period(Data display) display it every 2seconds
Menu 3/3 Moni/Level ：
AC
；Waveform output
Level ADJ ；Portable headphone output
-3，-2，-1，0，+1，+2，+3
AutoPwrOff ：
OFF
；Continuation operation
ON ；Automatic power is turned off after about
1 minute.
LCD cont ：
＊
；LCD contrast adjustment
＊ ・・・light
＊＊＊＊＊・・・deep
Baud rate ：4800，
9600
，19200 baud rate setup
Light
Lighting and putting out lights of a LCD back light.
Whenever it pushes, lighting and putting out lights are repeated.
Even if the light stays on, it automatically goes out in approx. 30 seconds
Cursor button
This is buttons for cursor operation, such as Mode/range, such as measurement conditions and
change.
<Change of the Measurement mode>
It changes ;
m/s
2
(ACC)
→
mm/s(VEL)
→
μm(DISP)
→
m/s
2
(ACC)
→
mm/s(VEL)
<Change of the Measurement Range>
Number on the right of a bar it changes; 200 → 20 → 200.
（In the case of displacement 2000 → 200）
<Change of the Display mode>
It changes ; RMS → Peak → EQPeak → （In the case of displacement, EQp-p → ）
Hand strap
When you have the main part of type3116 in hand, please let a hand pass to a hand strap
for fall prevention.
