a) Amplifier panel
Please, see Figure 5-6 eBox with ACOM 700S connected, Pos. (a).
Panel functional buttons:
• OFF and ON
Switch the amplifier OFF or ON;
• Save
When it is pressed the amplifier model change in a panel is saved;
Panel functional fields:
• Model
Allows selection of connected amplifier model. The supported models are ACOM 2000A,
600S, 700S, and 1200S;
• State
Displays the current state of the amplifier: Starting, Initializing, Standby, Powered OFF, or
Operate;
• Serial
Displays the amplifier serial number;
• FW, HW, Bootloader, Interface A, Interface B, and ATU Modem
Displays the versions of firmware, hardware, bootloader, Interface A and B, and ATU modem;
• Hard faults
Displays the number of stored hard faults in an amplifier memory.
b) User preferences panel
Please, see Figure 5-6 eBox with ACOM 700S connected, Pos. (b).
Thе panel contains different user settings for the amplifier.
For details about your ACOM amplifier, please, read corresponding User's Manual
(Sections Menu CAT/AUX SETTINGS, and Menu USER PREFERENCES).
The latest versions of our User's Manuals are available at www.acom-bg.com.
Panel functional buttons:
• Revert
When it is pressed the change in the panel will go back to the last saved value;
• Save
When it is pressed the changes in a panel are saved.
Panel functional fields:
• Antenna Tuner
Select on when a Remote Automatic Antenna Tuner and Switch ACOM 04AT is installed. If
there is no such device connected to the amplifier, error message will occur:
(113) ATU/ASEL unassigned automatically and out of service;
