Vehicle Diagnostics
4 – 30 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
4
4
From OBD II Function List:
1. Select
Record Data.
•Use
UP
or
DOWN
arrow
key until Record Data is
highlighted.
•Press
ENTER
.
✓ Follow all instructions on display.
✓ The ScanTool can maintain only one recording. Make sure to
thoroughly review old recording before erasing.
✓ If a recording currently exists in
memory, a message prompting to
erase data is displayed.
✓ Scan Tool validates list of global PIDs from vehicle.
2. Refer to View Data to setup Custom List or View Entire List.
✓ There are 2 types of trigger methods used:
❒ Manual Trigger - allows operator to use the
ENTER
key to
start recording.
❒ Trigger On Codes - automatically triggers when a diagnostic
trouble code (DTC) is detected by vehicle.
OBD II Function List
=====================
O2 Monitor Test
Diag Monitor Tests
On-Board Systems
Record Data
Vehicle Information
Modules Present
Review Data
MIL STATUS #1
ABSLT TPS
ENG SPEED #2”
CALL LOAD
MAP #4
COOLANT #3
IAT
IGN ADVANCE
