Vehicle Diagnostics
4
❒ SAE J1850 protocol is shown as VPWM or PWM.
OR
❒ ISO 15765-4 protocol is shown as CAN.
✓ Since CAN vehicles use module IDs larger than 2 digits, the Scan Tool
assigns a 2 digit module ID to be used in place of the actual CAN
module ID. The module ID assigned for the CAN module ID is used
in all functions of the Scan Tool.
=====================
ID Protocols
$10 VPWM*
$1A VPWM*
Modules Present
ID Protocols
$10 PWM*
$1A PWM*
Modules Present
=====================
ID Protocols
$01 CAN*7e9
$00 CAN*7e8
Modules Present
=====================
