the controller will shut the regulator down by removing drive to the input
contactor. This contactor will remain de-energized until the controller is
reset either by selecting the OFF position (remotely or locally) or cycling
the input power off for a minimum of 2 seconds and then back on. The
control board will not recognize momentary over currents caused by load
switching or other transient conditions.
O
PEN CIRCUIT PROTECTION
The micro-controller detects an open circuit by the absence of current in
the regulator output (this will also detect an open or shorted current
transformer). If the output current is less than 1.5 amps, the controller will
shut the current regulator down within one second by removing drive to
the input contactor. This contactor will remain de-energized until the
controller is reset either by selecting the OFF position (remotely or locally)
or cycling the input power off for a minimum of 2 seconds and then back
on.
Refer to Table 2-1 for required equipment that is supplied. Refer to
Table 2-2 for required equipment that is not supplied. Refer to Section 7
(Parts) for ordering information.
Table 2-1 Required Equipment Supplied
Description
Quantity
L-828 constant current regulator
As Req’d on Order
Instruction manual
1 per CCR on Order
Table 2-2 Required Equipment Not Supplied
Description
Quantity
Input power wire. Refer to Table 2-3.
As required
Remote control wire, AWG 19 minimum, AWG 14 maximum
As required
Ground wire, AWG 8 minimum (6.6 A); AWG 6 minimum (20 A)
As required
Output load wire, AWG 6 minimum, 5000 Vac, L-824 type (6.6 A); AWG 8 minimum
(20 A)
As required
Shorting jumper wire, AWG 8 minimum
As required
Disconnect switch or main circuit breaker
1
Input lightning arrestors for input voltages greater than 480 Vac. Mounted external to CCR.
NOTE: lightning arrestors are standard on the power input for voltages 480 Vac and less for all
new CCRs
As required
Voltmeter, 60 Vdc full scale
1
Ammeter, true rms-reading, 9 A maximum scale
1
Inductive-type current probe
1
Ohmmeter
1
Mounting bolts, ½-13 x 1-1/2 in. long, ½ STD washers, and lockwashers
4
7. Ferroresonant L-828 CCRs
(4-70 kW 6.6 A/20 A):
Required Equipment
