ADB Signature Series User Manual

Ferroresonant L-828/L-829 CCR Troubleshooting
 2009 ADB Airfield Solutions, Incorporated
96A0288T 6-3
All rights reserved Issued 9/04
This subsection provides information for troubleshooting fuses.
Refer to Table 6-1 for amp rating as a function of input voltage and CCR
kW rating for input power fuses F1 and F2 on the L-828 and L-829 CCRs.
Table 6-1 Input Power Fuses, F1 and F2, per CCR Input Voltage and CCR kW Rating
CCR Input
CCR kW Rating
Voltage
4 kW
(Fuse Part
Number)
7.5 kW
(Fuse Part
Number)
10 kW
(Fuse Part
Number)
15 kW
(Fuse Part
Number)
20 kW
(Fuse Part
Number)
30 kW
(Fuse Part
Number)
208 Vac
30 A,250V
(47A0092)
50 A,250V
(47A0093)
70 A, 250V
(47A0094)
110 A,250V
(47A0099)
125 A,250V
(47A0072)
200 A,250V
(47A0102)
240 Vac
25 A,250V
(47A0069)
45 A,250V
(47A0070)
60 A,250V
(47A0071)
80 A,250V
(47A0096)
110 A,250V
(47A0099)
175 A,250V
(47A0101)
480 Vac
12 A,600V
(47A0090)
25 A,600V
(47A0091)
30 A,600V
(47A0085)
50 A,600V
(47A0088)
60 A,600V
(47A0087)
90 A,600V
(47A0097)
CCR Input
CCR kW Rating
Voltage
50 kW
(Fuse Part
Number)
70 kW
(Fuse Part
Number)
480 Vac
125 A,600V
(47A0106)
200 A,600V
(47A0141)
Refer to Table 6-2. Fuses F3 and F4 on the L-828/L-829 CCRs protect
transformer T4, which supplies 110 Vac and 24 Vac to the universal
regulator control card.
Table 6-2 Transformer T3 Fuses F3 and F4 Ratings
CCR Input
CCR kW Rating
Voltage
4-10 kW
(Fuse Part Number)
15-70 kW
(Fuse Part Number)
208-240 Vac
2A, 250 V
(47A0113)
Not applicable
480 Vac
1 A, 500 V
(47A0108)
3 A, 500 V
(47A0187)
3. Troubleshooting Fuses
L-828/L-829 Input Power
Fuses F1 and F2
L-828 / L-829 Step-Down T4
Transformer Fuses F3 and F4
