ADB Signature Series User Manual

Ferroresonant L-828/L-829 CCR Description
 2009 ADB Airfield Solutions, Incorporated
96A0288T 2-11
All rights reserved Issued 9/04
This subsection provides specifications for L-828L-829 CCR
(4-70 kW 6.6 A/20 A).
4, 7.5, 10, 15, 20, 30, 50 and 70 kW
Refer to Table 2-5 for Class.
Table 2-5 Class
Class
L-828/L-829 CCR Output
1
6.6 A maximum output current
2
20 A maximum output current
Refer to Table 2-6 for Style.
Table 2-6 Style
Class
Style
Brightness Steps
Nominal Output Power
1
1
3
4.8 A, 5.5 A, 6.6 A
1
2
5
2.8 A, 3.4 A, 4.1 A, 5.2 A, 6.6 A
2
2
5
8.5 A, 10.3 A, 12.4 A, 15.8 A,
20 A
Refer to Table 2-7 for power factor.
Table 2-7 Power Factor
CCR
Power Factor
4 - 10 kW
0.90 minimum
15 -70 kW
0.95 minimum
The efficiency of the regulator operated with rated input voltage into a full
load having unity power factor is not less than the value shown in
Table 2-8.
Table 2-8 Efficiency
CCR
Efficiency
4-20 kW
0.90 minimum
30 kW
0.92 minimum
50 kW
0.93 minimum
70 kW
0.94 minimum
9. Specifications
Ratings
Class
Style
Power Factor
Efficiency
