Ferroresonant L-828/L-829 CCR Description
2009 ADB Airfield Solutions, Incorporated
96A0288T 2-10
All rights reserved Issued 9/04
NOTE: Table 2-3 refers to recommended input power supply.
Recommendation is based on 75°C rated copper wire per NEC Table
310.16.
Table 2-3 Recommended Input Wiring Rating
*Increased 1 wire size to comply with small conductor limits in NEC 240.4.D.
It is recommended that the circuit breaker on the input power supply lines
have a rating of 125% of the CCR’s input current, as given in Table 2-4,
unless local codes require a different rating technique. Refer to the CCR’s
nameplate for the kW rating and input voltage to determine the actual input
current from Table 2-4. If no standard-size circuit breaker exists at the
125% value, use the next larger standard-size circuit breaker.
NOTE: The currents listed in Table 2-4 represent actual input currents
assuming the worst case limits of AC 150/5345-10F for power factor,
efficiency, and number of required lamps out.
Table 2-4 CCR Input Current
CCRs (4-70 kW 6.6 A/ 20
A): Required Equipment
(contd.)
8. Input Power Breaker Sizing
To Next Page
