Ferroresonant L-828/L-829 CCR Parts

 2009 ADB Airfield Solutions, Incorporated

96A0288T 7-3

See Figure 7-2

Table 7-2 SGRS Powerpack (4-70 KW/6.6 A) Part Numbers

kW Rating

Output

Part Number

Seismic Zone 4

4 KW

6.6 A

PPF6604-X3XX

PPSF6604-X3XX

7.5 KW

6.6 A

PPF6607-X3XX

PPSF6607-X3XX

10 KW

6.6 A

PPF6610-X3XX

PPSF6610-X3XX

15 KW

6.6 A

20A

PPF6615-X3XX

PPF2015-X3XX

PPSF6615-X3XX

PPSF2015-X3XX

20 KW

6.6 A

20A

PPF6620-X3XX

PPF2020-X3XX

PPSF6620-X3XX

PPSF2020-X3XX

30 KW

6.6 A

20A

PPF6630-X3XX

PPF2030-X3XX

PPSF6630-X3XX

PPSF2030-X3XX

50 KW

20A

PPF2050-X3XX

PPSF2050-X3XX

30 KW

20A

PPF2070-X3XX

PPSF2070-X3XX

Figure 7-2 SGRS Powerpack Part Ordering Code

PPF6630-X 3 5 X

PPSF6630-X 3 5 X

4. SGRS Powerpack CCR (4-

70 kW/6.6 A) Part Ordering

Code

STAB CONNECTOR

CONNECTIONS

Blank = Vertical

H = Horizontal

MONITORING OPTIONS

0 = None

3 = L-829

4 = IRMS Only

5 = L-829 and IRMS

6 = L-828 with Digital Meter

INPUT

VOLTAGE

3 = 480

OUTPUT RANGE (Note

3 = 3 Step

4 = 3 Step with KIRK KEY

5 = 5 Step

6 = 5 Step with KIRK Key
