ADB Signature Series User Manual

Ferroresonant L-828/L-829 CCR Parts
 2009 ADB Airfield Solutions, Incorporated
96A0288T 7-2
All rights reserved Issued 9/04
Table 7-1 L-828/L-829 CCR (4-70 kW/6.6A & 20 A) Part Numbers
kW Rating
Output
240 V
480 V
4 kW
6.6 A
CCF6604-X2XX
CCF6604-X3XX
7.5 kW
6.6 A
CCF6607-X2XX
CCF6607-X3XX
10 kW
6.6 A
CCF6610-X2XX
CCF6610-X3XX
15 kW
6.6 A
CCF6615-X2XX
CCF6615-X3XX
20 kW
6.6 A
CCF6620-X2XX
CCF6620-X3XX
30 kW
6.6 A
CCF6630-X2XX
CCF6630-X3XX
15 kW
20 A
CCF2015-X2XX
CCF2015-X3XX
20 kW
20 A
CCF2020-X2XX
CCF2020-X3XX
30 kW
20 A
CCF2030-X2XX
CCF2030-X3XX
50Kw
20A
N/A
CCF2050-53XX
70kW
20A
N/A
CCF2070-53XX
CCF XX XX - X X X X
Figure 7-1 L-828/L-829 Part Ordering Code
3. L-828/L-829 CCR (4-70
kW/6.6 A/20 A) Part Ordering
Code
FIELD CIRCUITS MONITORED
0 = No field circuit monitoring
A = Field circuit monitoring
G = Field circuit monitoring, with input
CCR monitoring
MONITORING OPTIONS
0 = None
1= ALCS Scanning Monitor Interface
2 = ALCS Scanning Monitoring Ready
3 = L-829 ACE Monitoring
4 = IRMS Only
5 = L-829 Monitoring – ACE and IRMS
6 = L-828 with Digital Power Meter
INPUT VOLTAGE
1 = 208 (4-30 kW)
2 = 240 (4-30 KW)
3 = 480 (4-70 KW)
4 = 347
5 = 220 (4-30 KW)
OUTPUT VOLTAGE
3 = 3 Step without SCO Cutout
4 = 3 Step with SCO Cutout
5 = 5 Step without SCO Cutout
6 = 5 Step with SCO Cutout
SIZE
04 = 4kW /6.6A Only
07 = 7.5kW /6.6A Only
10 = 10kW/ /6.6A Only
15 = 15kW
20 = 20kW
30 = 30kW
50 = 50kW /20A Only
70 = 70kW/ 20A Only
AMPERAGE
66 = 6.6 amp (4-30kW)
20 = 20 amp (15-70kW)
