Ferroresonant L-828/L-829 CCR Description
 2009 ADB Airfield Solutions, Incorporated
96A0288T 2-15
All rights reserved Issued 9/04
Table 2-11 L-828/L-829 CCR Weight
Rating
208V
220V
240V
480V
4 kW
434
(196.9)
427
(193.7)
467
(211.8)
502
(227.7)
7.5 kW
556
(252.2)
480
(217.7)
514
(223.1)
600
(272.2)
10 kW
783
(355.2)
749
(339.7)
770
(349.3)
826
(374.7)
15 kW
960
(435.4)
872
(395.5)
826
(374.7)
906
(411.0)
20 kW
790
(358.3)
1397
(633.7)
1381
(626.4)
1097
(497.6)
30 kW
1410
(639.6)
1350
(612.3)
1381
(626.4)
1302
(590.6)
50 kW
Not applicable
Not applicable
Not applicable
2150
(975.2)
70 kW
Not applicable
Not applicable
Not applicable
2400
(1088.6)
CAUTION: The 50 and 70kW CCRs are very heavy. See
Section 3 for lifting instructions.
Table 2-12 L-828/L-829 CCR Dimensions
CCR
SIZE
208/220V
H x W x D (B x A x C)
240/480V
H x W x D (B x A x C)
4kW
33 x 24 x 25 in
(83.8 x 61 x 63.5 cm)
33 x 24 x 25 in
(83.8 x 61 x 63.5 cm)
7.5kW
36 x 29 x 30 in
(91.4 x 73.7 x 76.2 cm)
33 x 24 x 25 in
(83.8 x 61 x 63.5 cm)
10kW
36 x 29 x 30 in
(91.4 x 73.7 x 76.2 cm)
36 x 29 x 30 in
(91.4 x 73.7 x 76.2 cm)
15kW
40 x 33 x 34 in
(101.6 x 83.8 x 86.4 cm)
36 x 29 x 30 in
(91.4 x 73.7 x 76.2 cm)
20kW
40 x 33 x 34 in
(101.6 x 83.8 x 86.4 cm)
40 x 33 x 34 in
(101.6 x 83.8 x 86.4 cm)
30kW
40 x 33 x 34 in
(101.6 x 83.8 x 86.4 cm)
40 x 33 x 34 in
(101.6 x 83.8 x 86.4 cm)
50kW
Not applicable
70 x 33 x 34 in
(177.8 x 83.8 x 86.4 cm)
70kW
Not applicable
70 x 33 x 34 in
(177.8 x 83.8 x 86.4 cm)
