User Manual of TV5600-B01 Series Dispensing Control System
36
6.03 Example of editing dispensing path
We have completed the reset function. Based on this, we will explain how to complete the
teaching of a dispensing path through examples.
Sample demonstration steps:
① Select a program file.
② Create a programming point or a machining instruction.
③ Set the process parameters, known as file parameters; each program file has its file
parameters.
④ The first machining
6.03.01 Select program file
1. ->In handheld box monitoring interface,press [ ] button -> enter the file management
interface ->
-> Press to move the cursor (for example, move to the line of file No. 4) -> press [ ] to
open -> enter the file editing interface -> press again to set it to the editmode (white
background).
