Appendix II: List of Processing Instructions
Instr
uctio
n ID
Instructionn
ame
Function
1
Start point
Other axes except the Z axis are first set to the start position, then the Z axis
is lowered to the start position and the valve is opened
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
6) Delayopening mode: By default, the delayopening time in the file
parameter is used, or else the time set below is used
7) Delayopening time: Use this time when the delay opening mode is in
delay mode, or else this value is meaningless
8) Advance opening time: Use this time when the delay opening mode is in
advance mode, or elsethis value is meaningless
2
End point
After XYZ moves to the end point, the valve is closed and the Z axis is lifted to
the needle height
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
6) Use default advance closing distance: Select Yes to use the
advanceclosing distance gun file parameters, and select Noto use the
following advanceclosingdistance
7) Advance closingdistance: This value is meaningful when the default
value is not used as above
8) Default needle height: Select Yes to use the needle height in the file
parameters, and select No to use the needle height below
9) Needle height: This value is meaningful when the default value is not
used as above
3
Straight line
XYZ moves to the specified position by linear interpolation, and other axes
follow the movement to the specified position
1) XYZABC coordinates: Coordinates of each axis
