2) Circle center coordinate 1: The circle center coordinates of the 1st axis
of the plane where the ellipse is located
3) Circle center coordinate 2: The circle center coordinates of the 2nd axis
of the plane where the ellipse is located
4) Ellipse radius 1: Radius of the first axis of the ellipse plane
5) Ellipse radius 2: Radius of the second axis of the ellipse plane
6) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
12
End point of
ellipse
Specify the end point coordinates of the ellipse
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
13
Idle travel
Each axis moves to the specified position at the idle speed
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
16
Spline
Move to the specified position by Bezier spline interpolation
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
17
End point of
spline
End point of the Bezier curve
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
