Advanced MxPro4 User Manual

Specifications:
Item
Specification Details
Enclosure
Steel IP30
Steel IP30
Steel IP30
Steel IP30
Dimensions H
x W x D mm
475 x 450 x 125
475 x 450 x 190 (/D)
475 x 450 x 125
475 x 450 x 190 (/D)
950 x 450 x 190
950 x 450 x 190
Weight
(excluding
batteries)
10.5Kg / 12Kg (/D)
10.5Kg/ 12Kg (/D)
20Kg
23Kg
Temperature
-5°C to 40°C
-5°C to 40°C
-5°C to 40°C
-5°C to 40°C
Humidity
95 % Max
95 % Max
95 % Max
95 % Max
Cable Entries
(20mm
knockouts)
18x top, 9x top rear and 2x
bottom
36x top, 9x top rear (/D)
18x top, 9x top rear and 2x
bottom
36x top, 9x top rear (/D)
36x top, 9x top rear and 2x
bottom
36 x top, 9 x top rear and 2 x
bottom
Mains Supply
220-240V, +10%, -15%
47 –63 Hz AC
1 A max
220-240V, +10%, -15%
47 –63 Hz AC
1 A max
220-240V, +10%, -15%
47 –63 Hz AC
1 A max
220-240V, +10%, -15%
47 –63 Hz AC
2 A max
Battery
Capacity
24V 4Ah Internal (min)
24V 17Ah Internal (max)
(Mx4200)
24V 38Ah Internal (max)
(Mx4200/D)
24V 4Ah Internal (min)
24V 17Ah Internal (max) (Mx-
4400)
24V 38Ah Internal (max) (Mx-
4400/D)
24V 4Ah Internal (min)
24V 48Ah Internal (max) (2x
24Ah in parallel)
2x 24V 4Ah Internal (min)
2x 24V 38Ah Internal (max)
Charging
Current
2.4A
Temperature Compensated
2.4A
Temperature Compensated
2.4A
Temperature Compensated
2 x 2.4A
Temperature Compensated
Max Battery
Resistance
(+/-10%)
1.5Ω
1.5Ω
1.5Ω
1.5Ω
Power Supply
Separate 24V DC, 4A
Off-Line
Switched Mode
Separate 24V DC, 5A
Off-Line
Switched Mode
Separate 24V DC, 5A
Off-Line
Switched Mode
2x Separate 24V DC, 5A
Off-Line
Switched Mode
Imax(a) =
Imax(b)
2.6A
2.6A
2.6A
2.6A
Output
Voltage
1
18.5V – 28.0V
18.5V – 28.0V
18.5V – 28.0V
18.5V – 28.0V
Ripple (Vpkpk)
1.0V
1.0V
1.0V
1.0V
Number of
Fire Zones
200 max, across 2 loops
(1000 when networked)
200 max, across 4 loops
(1000 when Networked)
200 max, across 4 loops
(1000 when Networked)
400 max, across 8 loops
(1000 when Networked)
Number of
Loops
1 to 2
1 to 4
1 to 4
2 to 8
Devices per
Loop
240
2
Loop Current
3
(max. / Loop)
400mA quiescent
500mA alarm
400mA quiescent
500mA alarm
400mA quiescent
500mA alarm
400mA quiescent
500mA alarm
Protocols
ADVANCED / ARGUS VEGA
Sounder
3
Outputs
2 x 1A Programmable
4 x 1A Programmable
4 x 1A Programmable
8 x 1A Programmable
Relay Outputs
2 x 1A 30V AC/DC (max)
10mA. 5V (min)
Programmable
2 x 1A 30V AC/DC (max)
10mA. 5V (min)
Programmable
2 x 1A 30V AC/DC (max)
10mA. 5V (min)
Programmable
4 x 1A 30V AC/DC (max)
10mA. 5V (min)
Programmable
Open
Collector
Outputs
2 x Programmable
10mA 30V DC (max)
2 x Programmable
10mA 30V DC (max)
2 x Programmable
10mA 30V DC (max)
4 x Programmable
10mA 30V DC (max)
Digital Outputs
6 x Programmable
6 x Programmable
6 x Programmable
12 x Programmable
Auxiliary
Supply Output
3
24V DC, 500mA
24V DC, 500mA
24V DC, 500mA
2 x 24V DC, 500mA
Event Log
1000 Event & Diagnostic + 500 Fire
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice
1
Minimum/maximum specifications for the AUX, and Sounder outputs. Detector Loop voltage is not dependant on AC or battery voltage.
2
See Section 2.6.3 for details of EN54-2 detection device limits.
3
Total output current and panel load should not to exceed Imax(a).
